Description
An accurate way to determine which series of PTO you have is to take two measurements of the cross and bearing kit on the tractor-end. Using calipers, first measure the outside diameters of the u-joint caps, which would be the same as measuring the inside holes of the yoke ears.
Secondly, measure the u-joint end-to-end both ways. Match these measurements using a cross and bearing identification chart and the remaining PTO parts needed for the complete driveline can be determined with ease.
| Spec. | Imperial | Metric |
|---|---|---|
| Bore 1 | 1.50 inches | 38 mm |
| Bore 1 | ROUND | |
| Connection 1 | PIN | |
| Height | 4.00 inches | 102 mm |
| HP@1000RPM | 108 HP | 81 kilowatts |
| HP@540RPM | 70 HP | 52 kilowatts |
| Length | 4.19 inches | 106 mm |
| Pin Hole | 0.25 inches | 6 mm |
| Shear Bolt | (1) 1/2 Grade 8 | |
| Shipping Dimensions | 5.07" L × 4" H × 2.34" W | 13cm L × 10cm H × 6cm W |
| Shipping Volume | 47.46 in3 | 778 cm3 |
| Shipping Weight | 3.06 pounds | 1 kilograms |
| Torque | 12000 | 12000 |
| Weight | 3.06 pounds | 1 kilograms |
| Width | 2.34 inches | 59 mm |
